| color | EDP | TARGET HOLE DIAMETER (MM) | D3 BRUSH SIZE (MM) | L1 OVERALL LENGTH (MM) | L4 BRUSH LENGTH (MM) | D1 SHANK DIAMETER (MM) | D2 NECK DIAMETER (MM) | MAX RPM | Product Number |
|---|---|---|---|---|---|---|---|---|---|
| RED | 20007 | 3.5 to 5 | 1.5 | 120 | 50 | 3 | 2.5 | 20,000 | CH-A12-1.5M |
| BLUE | 20008 | 5 to 8 | 3 | 130 | 60 | 3 | 4 | 14,000 | CH-A33-3M |
| BLUE | 20012 | 5 to 8 | 3 | 180 | 60 | 4 | 4 | 12,000 | CH-A33-3L |
| RED | 20001 | 5 to 8 | 3 | 120 | 50 | 3 | 4 | 14,000 | CH-A12-3M |
| RED | 20004 | 5 to 8 | 3 | 170 | 50 | 4 | 4 | 14,000 | CH-A12-3L |
| BLUE | 20009 | 8 to 10 | 5 | 130 | 60 | 6 | 6 | 14,000 | CH-A33-5M |
| BLUE | 20013 | 8 to 10 | 5 | 180 | 60 | 6 | 6 | 12,000 | CH-A33-5L |
| RED | 20002 | 8 to 10 | 5 | 120 | 50 | 6 | 6 | 14,000 | CH-A12-5M |
| RED | 20005 | 8 to 10 | 5 | 170 | 50 | 6 | 6 | 14,000 | CH-A12-5L |
| BLUE | 20010 | 10 to 14 | 7 | 130 | 60 | 6 | 8 | 14,000 | CH-A33-7M |
| BLUE | 20014 | 10 to 14 | 7 | 180 | 60 | 8 | 8 | 12,000 | CH-A33-7L |
| RED | 20003 | 10 to 14 | 7 | 120 | 50 | 6 | 8 | 14,000 | CH-A12-7M |
| RED | 20006 | 10 to 14 | 7 | 170 | 50 | 8 | 8 | 14,000 | CH-A12-7L |
| BLUE | 20011 | 14 to 20 | 11 | 130 | 60 | 12 | 12 | 14,000 | CH-A33-11M |
| BLUE | 20015 | 14 to 20 | 11 | 180 | 60 | 12 | 12 | 12,000 | CH-A33-11L |
| RED | 20017 | 14 to 20 | 11 | 170 | 50 | 12 | 12 | 12,000 | CH-A12-11L |
| RED | 20018 | 14 to 20 | 11 | 120 | 50 | 12 | 12 | 14,000 | CH-A12-11M |
| DARK BLUE | 20021 | 20 to 25 | 15 | 150 | 60 | 6 | 16 | 9,000 | CH-A34-15 |
| DARK BLUE | 20022 | 25 to 30 | 20 | 150 | 60 | 8 | 21 | 9,000 | CH-A34-20 |
| DARK BLUE | 20023 | 30 to 35 | 25 | 150 | 60 | 8 | 26 | 9,000 | CH-A34-25 |
 |
